Teltonika’s TeltoCharge (Gen 2)

The future of smart EV charging on your wall. Convenient, efficient and highly customisable home & small business charger to match your style.

We highly recommend purchasing this smart EV charger with the Carlo Gavazzi Meter to enable dynamic load management.

Compatible with all EV brands!

Home EV charging – Manage existing power demands e.g. underfloor heating, electric ovens, induction hobs etc.
Apartment charging that requires billing for a communal power supply and cost recovery.
Business fleet at home EV charging – Support business charging at some by tracking and reimbursing for private energy use.
Small businesses – Support small business fleets with detail reporting of energy use

Features

Power up to 7.4 kW charging capacity allowing you to quickly charge your EV faster up to three times faster than a three-pin plug.
Advanced load balancing. Charging an EV can put a strain on your home or building’s power and fuse board. Teltonika’s market-leading load balancing device offers static, dynamic and phase balancing which means you can be sure that your home or building’s power source is not compromised. Included current transformer (CT clamps) simplify installation to provide the load balancing functionality.
Integral fault protection. Built-in PEN fault protection provides an additional safety measure to protect the user against faults and fluctuations in the electrical supply during the charging process.
Several connectivity options. With a variety of connectivity options including Ethernet, SIM card, Bluetooth and WiFi, this charger can be seamlessly integrated into your premise.
A variety of access options

- Free access enabling users to simply plug in and charge (suitable for home chargers or free public charging)
- Requires a RFID tag to unlock the charger (suitable for locations where you want to guard access)
Customise your settings via the web interface Access in-depth insights into your charging, set charging guidelines and power limits for smart, cost-efficient charging.
LED status indicators Dynamic and multicolored LED lights showing charging status, authentication, and more.
Monitor user and charge session data Monitor charge session data reports. If you need a charger for staff homes, apartment body corporates and more, we can set up a billing system to track time or energy consumed.
Designed to last This charger has several face plate options to complement or blend into its installed location. It also features robust external shell and reliable build quality, which can withstand even the harshest weather. It is IP56 and IK10 rated, meaning that it can be safely installed both indoors and outdoors.
Built-in electrical safety protection With built-in monitoring to keep tabs on output voltage and current, temperature, input voltage, and ground fault detection, the Teltonika units can confidently be installed anywhere with a three-year guarantee.

Specifications

Tethered cable with Type 2 outlet (IEC 62196-2)
Type 2 socket (IEC 62196-2)
Up to 7.4kW charging power on single-phase power
Dynamic LED status indicators
Device connectivity via WiFi, Bluetooth, Ethernet, Cellular networks, RFID (NFC) reader, and Modbus/RS485
Inbuilt protection monitoring of temperature, voltage, current, and electrical supply neutral faults
Open Charge Point Protocol (OCPP)
T/N and IT/TT network types
1.6 OCPP and JSON communication protocols available
Protection IP56 (ingress protection rating) and IK10 (knock rating)
Dimensions: Width 170mm / Height 341mm / Depth 94mm
